A&H XONE:96 6 into 2 Club & DJ mix 2 x 96k soundca

Type Analogue
Channels 6 + 2
EQ
Channel 1-4, 4-Band EQ
Channel A-B, 3-Band Parametric EQ
USB Soundcards Dual 24 Channel (12 in / 12 out)
Hi-Speed USB2.0 / Mac Class Compliant
32bit / 96kHz
MIDI over USB
Line Inputs 4 x RCA (CH 1-4)
4 x 1/4? TRS (CH A-D) Mono/Stereo
Phono Inputs 4 x RCA (CH 1-4)
LN/PH Switch for DVS
USB Inputs 6 x USB (CH 1-4 + CH A – CH B)
Mic Input 2 x XLR
Master Output 1 x XLR (Balanced)
Master 2 Output 1 x 1/4? TRS (Balanced)
Booth Output 1 x 1/4? TRS (Balanced)
Record Output 1 x RCA (Un-balanced)
Master Insert 1 x 1/4? TRS
MIDI Out 1 x 5-Pin DIN
Send/Return I/O
2 x 1/4? TRS Send
4 x 1/4? TRS Return
1 x LN/Hi-Z Switch (SND1/RTNA)
Filter
2 x VCF Filter
HPF / BPF / LPF
Adjustable Frequency & , Resonance
Assignable CH 1-4 + CH A-B
CRUNCH (Controlled Harmonic Signal Distortion)
X-Link 1 x RJ45
Headphones
2 x 1/4?
2 x 3.5mm
Split Cue Monitoring
Channel Faders 60mm VCA / Replaceable
Chanel Meters 9 Segment LED
Channel Fader Curve 3 Types
X-Fader InnoFADER / 45mm VCA / Replaceable
X-Fader Curve 3 Types
Earth Ground Terminals x 2
Headroom 20dB
AC Mains
100 to 240V
AC 50/60Hz
Consumption 45W max
Mains Adaptor 3 pin IEC socket
Height 109mm / 4.3?
Width 336mm / 13.25?
Depth 410mm / 16.2?
Weight 7kg / 15.4 lbs.

  ,
