Klotz H1A55NT DMX and power hybrid cable with XLR 5p. and powerCON TRUE1
hybrid cable suitable for analogue and digital signals
power cable: 3 x 1.5 mm²
the powerCON TRUE1 is a connector with breaking capacity (CBC), i.e. it can be connected or disconnected under load or live.

A hybrid cable that combines power, audio and DMX conductors in a single product is the ideal solution. It significantly reduces cabling work – a particular advantage where long distances are involved. With characteristic impedance of 110 ?, the double-shielded signal conductor is suitable for transmission of analogue audio signals as well as digital AES/EBU and DMX signals. However, the logic of the DMX standard is the precise opposite of audio XLR logic , in DMX, the female connector is on the transmitter side and the male connector is on the receiver.
The rugged PVC outer jacket encloses the finely stranded power cable with cross-section of 3 x 1.5 mm2 and the double-shielded signal conductor (foil and braided copper shields). The cables are available with all common connector options: XLR 3p. and 5p., powerCON, power CON A, powerCON TRUE1, earthed plug and IEC (low-power).
