Klotz TrussLink 12 ch - 12-12 XLR 2x RMP M-F - single ground

Klotz ST1212MFE TrussLink 12 channels - 12||12 XLR + 2x RMP M/F - single ground
audio stagebox with significantly increased functionality
pairs of parallel connected XLR 3p. F/M can be used as send or return
easy weight, solid aluminium chassis, black grey powder coating
non-skid due to solid mounted rubber bases
slip-proof rubber feet, M10 screw thread and four holes for safety lanyards
always stays firmly in position - whether it is used free-standing or attached to a rig
compatible with LK connectors, Tourline and CIRLK, as well as other connectors according to MIL C 5015 standard

TrussLink Stage Boxes are dependable companions where professionalism is required. Their paired parallel  ,
configurations of XLR connectors (XLR 3p. F/M) can be used as both inputs and outputs. This maximizes their  ,
flexibility in professional stage work and speeds up setup and take-down times.  ,
The rugged aluminium housing has non-slip rubber feet and laser-engraved labelling. The RMP connectors  ,
feature the F/M logic that we have used throughout the product line. The ideal choice for transmitting  ,
signals from the stage to the FOH or submixer and back. With four suspension loops on the housing and an  ,
M10 thread in the base for a Manfrotto Superclamp, the Return Stage Boxes are designed for use with stage trusses.  ,
They’re also digital-ready, with internal cabling that’s tailored to characteristic impedance of  ,
110 ohms – vital for use as DMX or AES/EBU box. TrussLinks are great for a whole range of roles, from  ,
small sub-stage boxes to complete multicore systems.
The TrussLink parallel stagebox models are available in 8-channel and 12-channel models with one or two  ,
RMP connectors, and optionally with 5-pin XLR connectors for DMX applications.
