SKU
AURI-D4-0
Listen Auri Docking Station 4
- Lader 4 mottakere av gangen
veil. inkl. MVA. veil eks. MVA
Din pris per Stk Veil. per Stk inkl. mva. eks. MVA.
Kontakt vår ekspert om dette produktet
Dokkingstasjonene sørger for lading og administrasjon av Auri™-mottakere og er tilgjengelige i 4 eller 16 enhetsalternativer, med tilbehør som dokkingstasjonsdekselet og kabelhåndteringsenhet for Auri-D16.
Inkluderer
- 1 X Auri dokkingstasjon 4
- 1 x LA-210 strømforsyning
- 1 x Hurtigstartguide og sikkerhetsdatablad
+Network
| Port Speed | 100 Mbit |
| IP Address | DHCP, static or link-local |
| Protocols | mDNS, UDP (unicast), RTP (multicast), RTCP (multicast) |
| Security | UDP communication AES26-GCM |
+Controls
| Buttons | Copy and Status Buttons |
| Buttons | Recessed restart and factory reset buttons |
| Setup/Programming | Via Auri™ Manager Software over network |
| LEDs | Copy LED (red) and Status LED (amber), see handbook for states |
+Power
| Power Supply Input | 100-240 VAC, 50-60 Hz |
| Power Supply Output | 12 VDC, 4.0 A, 48 W |
| Power Supply Connector | 5.5 mm (.22 in) OD x 2.3 mm (.09 in.) ID, barrel type |
| Power Cable | 1.8 m (72 in.) Input Power Cable, 1.1 m (43 in.) Output Cable |
+Physical
| Dimensions | 50 x 192 x 150 mm (1.97 x 7.56 x 5.89 in) |
| Unit Capacity | 4 Units |
| Weight | .65 kg (1.43 lbs.) |
| Shipping Weight | 1.56 kg (3.44 lbs) |
| Color | Black with Chrome Buttons |
| Mounting | Place on flat surface or use wall mounting slots |
+Environmental
| Temperature - Storage | -40 °C (-40 °F) to 70 °C (+158 °F) |
| Temperature - Operation | -10 °C (14 °F) to 40 °C (+104 °F) |
| Relative Humidity | 0 to 95% relative humidity, non-condensing |
| IP Rating | IP20 |
+Compliance
| Standards | CE, UKCA, RCM, REACH, WEEE |
+Network Requirements
| Device Discovery | mDNS (Multicast) 224.0.0.251 |
| Control | uDP (Unicast) Device IP (DHCP, Static, or Link Local) |
| Firmware Update | TFTP |
| SKU | AURI-D4-0 |
|---|---|
| Vekt (kg) | 0.000000 |
| Fabrikant | Ampetronic |
| Produktserie | AURI (AuraCast™ Broadcast Audio) |
| Produkttype | Dockingstasjon |
| Farge | Svart |
