Listen ListenIR 1-Channel Transmitter

Hjertet i Listen Technologies ListenIR-systemet er LT-82 enkanalssenderen. LT-82 kan fungere i enten mono- eller stereomodus, og overfører lydsignalet ditt til og gir likestrøm til en eller flere LA-140 infrarøde radiator-/emitterenheter.

veil. inkl. MVA. veil eks. MVA
Din pris per Stk Veil. per Stk inkl. mva. eks. MVA.

Kontakt vår ekspert om dette produktet

Hjertet i Listen Technologies ListenIR-systemet er LT-82 enkanalssenderen. LT-82 kan fungere i enten mono- eller stereomodus, og overfører lydsignalet ditt til og gir likestrøm til en eller flere LA-140 infrarøde radiator-/emitterenheter gjennom en standard CAT-5-kabel. I tillegg kan enheter kombineres for å tilby opptil fire (4) kanaler med mono- eller stereolyd for utvidede applikasjoner.

LT-82-senderen er en ideell infrarød sender for et bredt spekter av assisterende lyttebehov, inkludert teatre, bedehus, språktolkning og mer.

Inkluderer
En (1) LT-82 ListenIR 1-kanals sender
Én (1) LA-205 30 VDC utvidelses-/erstatningsstrømforsyning for LA-140/LT-82
En (1) LA-89 sammenkoblingskoaksialkabel
Ett (1) hurtigreferansekort


Høydepunkter

  • Utvidbar og rimelig senderenhet for infrarøde hjelpelyttesystemer
  • Gir likestrøm for opptil to (2) LA-140 radiator-/emitterenheter via standard CAT-5-kabling
  • Lydsignal leveres til LA-140 radiator/emitter-enheter via RG-58 koaksialkabel
  • Sender opptil fire (4) kanaler med mono- eller stereolyd (én kanal per LT-82-enhet)
  • Krystallklar og sikker lydytelse for arenaer, bedehus, møter, konferanserom og mer

Audio

Frequency Response 63 Hz - 15 kHz (+/- 3 dB)
Signal-to-Noise Ratio Mono: > 60 dBStereo: > 52 dB
System Distortion < 2% total harmonic distortion (THD)
Audio Input 1 Mono Input (Rear Panel). Female-XLR and 1/4 in. combo connector, balanced, 0/-55 dBu (line/mic) nominal input level adjustable; +21/-30 dBu (line/mic) maximum input level; impedance 20k/1k ohms (line/mic); phantom power +12 VDC
Audio Input 2 Stereo or Mono Input (Rear Panel). Two (2) Phono connectors, unbalanced, -10/+10 dBu nominal input level adjustable, +30 dBu maximum, impedance 100k
Audio Processing Compression can be turned on/off.
Contour Cuts and boosts frequencies above 5 kHz
Monitor Output Front panel. One (1) 3.5 mm (0.14 in.) connector, unbalanced, adjustable output level, +7 dBu maximum, impedance 10 ohms. 100 mW, 32 ohms
Output/s Input 1 and Input 2 Mixed Output (Rear panel). Two (2) Phono connectors, unbalanced, -10 dBu nominal output level, +19 dBu maximum, impedance 10 ohms

Controls

Programming Stereo on/off, Processing on/off
Front Panel Power, Test Tone on/off, Channel up/down, Input Level, Transmit Level, Contour, Monitor Level
Rear Panel Input 1 Level (Line, Mic, Mic-Phantom Power), Input 2 Level (-10/+10 dBu)
Internal Adjustments Compression ratio for audio processor. Slope adjustable from 1:1 to 4:1. Default 2:1

Indicators

LCD Channel designation, lock status, RF Carrier, programming (front panel)
Unit Power Red LED illuminates when the unit is powered up (front panel)
Input 1, Input 2, Transmit Level Indicates Input 1, Input 2, and Transmit audio levels. 10 segment LED's (8 green, 2 red)
Stereo Indicated by a green LED when on (front panel)
Processing Indicated by a green LED when on (front panel)
RF Carrier Indicates carrier is active on the LCD Display (front panel)
Test Tone Red LED illuminates when test tone enabled (front panel)

RF

Input/s One (1) BNC connector, for connection from additional transmitter(s). 50 mV, 50 ohm, -15 dBm
Output/s Two (2) BNC connectors, for connection to radiator(s) and/or additional transmitter(s). 50 mV, 50 ohm, -15 dBm
Carrier Frequencies 2.3 MHz, 2.8 MHz, 3.3 MHz, 3.8 MHz
Number of Channels Four (4) channels. Selectable one (1) channel per transmitter (mono or stereo)
Frequency Accuracy +/- .005% stability 0 to 50 °C
Carrier Shut Off Carrier will shut off when no audio is present for 30 minutes to preserve radiator life.
Transmitter Stability 50 PPM

Power

Power Supply In-line switching mode power supply, Listen part number LA-205
Power Supply Input 100-240 VAC, 47-63 Hz
Power Supply Output 30 VDC, 1.5 A
Power Supply Connector RJ-45
Power Output Two (2) RJ-45 jacks. For remote powering up to two (2) radiators

Physical

Width 8.50 in. (21.5 cm)
Height 1.75 in. (4.5 cm)
Depth 9.13 in. (23 cm)
Color Dark Grey
Unit Weight with Power Supply 3.8 lbs. (1.72 kg)
Shipping Weight 6.0 lbs. (2.7 kg)
Rack Mounting One (1) rack space high (1U), 1/2 rack space wide. One (1) or two (2) transmitters can be mounted in a single rack space. Optional Rack mount (LA-326) not included.
Weight 2.6 lbs. (1.18 kg)
Power Line Cord IEC line cord, North America Type B (LT-84-01), Asia and UK Type G (LT-84-02), Euro Type F (LT-84-03), Australia Type I (LT-84-04)

Environmental

Temperature - Operation 14 °F (-10 °C) to +104 °F (40 °C)
Temperature - Storage -4 °F (-20 °C) to +122 °F (50 °C)
Relative Humidity 0 to 95% relative humidity, non-condensing

Compliance

Standards FCC Part 15, Industry Canada, CE, RoHS, UL
Mer informasjon
SKULT-82-03
Vekt (kg)0.000000
EnhetStk
FabrikantListen Technologies
ProduktserieListenIR
ProdukttypeSender
KonfigurasjonRack 1/2U
StrømkravEkstern strømforsyning +30VDC RJ45 kontakt
FargeSvart

Hjertet i Listen Technologies ListenIR-systemet er LT-82 enkanalssenderen. LT-82 kan fungere i enten mono- eller stereomodus, og overfører lydsignalet ditt til og gir likestrøm til en eller flere LA-140 infrarøde radiator-/emitterenheter gjennom en standard CAT-5-kabel. I tillegg kan enheter kombineres for å tilby opptil fire (4) kanaler med mono- eller stereolyd for utvidede applikasjoner.

LT-82-senderen er en ideell infrarød sender for et bredt spekter av assisterende lyttebehov, inkludert teatre, bedehus, språktolkning og mer.

Inkluderer
En (1) LT-82 ListenIR 1-kanals sender
Én (1) LA-205 30 VDC utvidelses-/erstatningsstrømforsyning for LA-140/LT-82
En (1) LA-89 sammenkoblingskoaksialkabel
Ett (1) hurtigreferansekort


Høydepunkter

  • Utvidbar og rimelig senderenhet for infrarøde hjelpelyttesystemer
  • Gir likestrøm for opptil to (2) LA-140 radiator-/emitterenheter via standard CAT-5-kabling
  • Lydsignal leveres til LA-140 radiator/emitter-enheter via RG-58 koaksialkabel
  • Sender opptil fire (4) kanaler med mono- eller stereolyd (én kanal per LT-82-enhet)
  • Krystallklar og sikker lydytelse for arenaer, bedehus, møter, konferanserom og mer

Audio

Frequency Response 63 Hz - 15 kHz (+/- 3 dB)
Signal-to-Noise Ratio Mono: > 60 dBStereo: > 52 dB
System Distortion < 2% total harmonic distortion (THD)
Audio Input 1 Mono Input (Rear Panel). Female-XLR and 1/4 in. combo connector, balanced, 0/-55 dBu (line/mic) nominal input level adjustable; +21/-30 dBu (line/mic) maximum input level; impedance 20k/1k ohms (line/mic); phantom power +12 VDC
Audio Input 2 Stereo or Mono Input (Rear Panel). Two (2) Phono connectors, unbalanced, -10/+10 dBu nominal input level adjustable, +30 dBu maximum, impedance 100k
Audio Processing Compression can be turned on/off.
Contour Cuts and boosts frequencies above 5 kHz
Monitor Output Front panel. One (1) 3.5 mm (0.14 in.) connector, unbalanced, adjustable output level, +7 dBu maximum, impedance 10 ohms. 100 mW, 32 ohms
Output/s Input 1 and Input 2 Mixed Output (Rear panel). Two (2) Phono connectors, unbalanced, -10 dBu nominal output level, +19 dBu maximum, impedance 10 ohms

Controls

Programming Stereo on/off, Processing on/off
Front Panel Power, Test Tone on/off, Channel up/down, Input Level, Transmit Level, Contour, Monitor Level
Rear Panel Input 1 Level (Line, Mic, Mic-Phantom Power), Input 2 Level (-10/+10 dBu)
Internal Adjustments Compression ratio for audio processor. Slope adjustable from 1:1 to 4:1. Default 2:1

Indicators

LCD Channel designation, lock status, RF Carrier, programming (front panel)
Unit Power Red LED illuminates when the unit is powered up (front panel)
Input 1, Input 2, Transmit Level Indicates Input 1, Input 2, and Transmit audio levels. 10 segment LED's (8 green, 2 red)
Stereo Indicated by a green LED when on (front panel)
Processing Indicated by a green LED when on (front panel)
RF Carrier Indicates carrier is active on the LCD Display (front panel)
Test Tone Red LED illuminates when test tone enabled (front panel)

RF

Input/s One (1) BNC connector, for connection from additional transmitter(s). 50 mV, 50 ohm, -15 dBm
Output/s Two (2) BNC connectors, for connection to radiator(s) and/or additional transmitter(s). 50 mV, 50 ohm, -15 dBm
Carrier Frequencies 2.3 MHz, 2.8 MHz, 3.3 MHz, 3.8 MHz
Number of Channels Four (4) channels. Selectable one (1) channel per transmitter (mono or stereo)
Frequency Accuracy +/- .005% stability 0 to 50 °C
Carrier Shut Off Carrier will shut off when no audio is present for 30 minutes to preserve radiator life.
Transmitter Stability 50 PPM

Power

Power Supply In-line switching mode power supply, Listen part number LA-205
Power Supply Input 100-240 VAC, 47-63 Hz
Power Supply Output 30 VDC, 1.5 A
Power Supply Connector RJ-45
Power Output Two (2) RJ-45 jacks. For remote powering up to two (2) radiators

Physical

Width 8.50 in. (21.5 cm)
Height 1.75 in. (4.5 cm)
Depth 9.13 in. (23 cm)
Color Dark Grey
Unit Weight with Power Supply 3.8 lbs. (1.72 kg)
Shipping Weight 6.0 lbs. (2.7 kg)
Rack Mounting One (1) rack space high (1U), 1/2 rack space wide. One (1) or two (2) transmitters can be mounted in a single rack space. Optional Rack mount (LA-326) not included.
Weight 2.6 lbs. (1.18 kg)
Power Line Cord IEC line cord, North America Type B (LT-84-01), Asia and UK Type G (LT-84-02), Euro Type F (LT-84-03), Australia Type I (LT-84-04)

Environmental

Temperature - Operation 14 °F (-10 °C) to +104 °F (40 °C)
Temperature - Storage -4 °F (-20 °C) to +122 °F (50 °C)
Relative Humidity 0 to 95% relative humidity, non-condensing

Compliance

Standards FCC Part 15, Industry Canada, CE, RoHS, UL
Mer informasjon
SKULT-82-03
Vekt (kg)0.000000
EnhetStk
FabrikantListen Technologies
ProduktserieListenIR
ProdukttypeSender
KonfigurasjonRack 1/2U
StrømkravEkstern strømforsyning +30VDC RJ45 kontakt
FargeSvart
