Neutrik BNC 75 OHM UHD rearTWIST Klotz V10/48 Belden 4694

Neutrik NBNC75BTU11X

The rearTWIST UHD BNC connectors are specifically designed for high resolution video signal transmissions.  ,
Due to the unique insulator and contact pin design, the connectors feature low return loss values  ,
for 4K and 8K signals.

  ,
Features & , Benefits

Optimized contact pin and insulator design for UHD-data transmissions
Proven rearTWIST technology
Swiss antraloy plating
Fully compatible with conventional BNC chassis connectors
Improved return loss values at high frequencies
  ,

Optimized Return Loss

Due to optimized insulator design and reduced crimp diameter from center pin the Neutrik rearTWIST UHD BNC  ,
connector achieves increased headroom compared to conventional BNC connectors and offers additional return  ,
loss reserve for potential impedance deviations resulting from cable bending, incorrect connector assembly  ,
or faulty connection interfaces without signal interruption.


Crimp Dimensions

In order to achieve optimum return loss values at high frequencies the crimp dimension of the contact pin  ,
has been reduced.

Pin: 1.07 mm
Shield: 7.36 mm
Crimp die:  , DIE-R-BNCX-PU

  ,

Approved Cables

To guarantee high performance for each cable-connector combination at high frequencies Neutrik measured  ,
common COAX cables which are specifically designed for ultra high definition transmission (UHD).  ,
Find all approved cables listed below.

Suitable cables:
CommScope 5765, Gepco VSD2001, Suhner S05163-02, Suhner S05133-07, Percon VK77

UHD optimized cables:
Argosy Image 1000, Belden 1694A, Belden 1694ANH, Belden 1694DNH, Belden 4694R, Belden 70082,  ,
Belden 70082NH, Belden 70082CH, Bryant SD11, Bryant SD10F, Canare L-4.5CHWS, Canare L-4.5CHD,  ,
Clark Wire CD7506, Klotz V10/48, Klotz V10/48H
