Neutrik ,NE8MX6-T
etherCON CAT6A cable connector self-termination, for insulation diameter ? 1.1 mm, nickel plating
The set NE8MX6 consists of a cable plug carrier offering a robust metal shell, proven Neutrik chuck-type strain relief and a CAT6A compliant RJ45 plug. The set is suitable for a cable diameter range of 7 mm to 9.5 mm and wire gauge of AWG26/1 - AWG22/1 (solid) or AWG27/7 - AWG22/7 (stranded).
If the insulation diameter is > , 1.1 mm please refer to NE8MX6.
Attention! Does not intermate with the CAT6 chassis connectors NE8FDY-C6 and NE8FDY-C6-B.
Features & , Benefits
Ruggedized connector with CAT6A component compliance according to ISO/IEC 11801 and TIA/EIA 568-C.2
PoE+ compliant according to 802.3at Type2
IP65 protected when mated with NE8FDX-P6-W or NE8FDX-Y6-W
Rugged latch lock system million fold proven
Intermateable with the existing etherCON CAT5 range
Unique Neutrik chuck-type strain relief
| SKU | NE8MX6-T |
|---|---|
| Vekt (kg) | 0.050000 |
| Enhet | Stk |
| Fabrikant | Neutrik |
| Han-/Hunkjønn | Hankjønn |
| Antall poler | 3-pins |
| Farge | Nikkel |
| CAT Standard | CAT6a |
