SKU
NE8MC6-MO
Neutrik EtherCON RJ45 CAT6 plugg IP65
Pris på forespørsel
Kontakt vår ekspert om dette produktet
Aksel E. Holand
Aksel er merkevareansvarlig for Klotz, Neutrik, Sonifex og Ambient.
aeh@benum.com +47 970 55 952 send e-post
Neutrik NE8MC6-MO
Neutrik EtherCON Cat6 selvterminerende han for kabel. ,Attention! Does not intermate with CAT5 and CAT6A chassis connectors.
The set NE8MC6-MO includes a cable plug carrier offering a robust metal shell with Push-Pull locking system, proven Neutrik chuck-type strain relief and a CAT6 RJ45 plug. The set can accommodate STP und UTP cables with O.D. of 5.5 to 6.5mm and gauge of AWG 22 to 28 solid or stranded wire. This self-termination version is water protected according to IP65.
,
Features & , Benefits
- Complies with CAT6 specifications according to TIA / EIA 568B, ISO / IEC 11801, EN 50173
- CAT6 compliant - data rate up to 10 GBit/s
- IP65 - Dust and waterproof in mated condition
- Shielded system - high noise immunity and EMI protection
- Push Pull mating - secure and proven locking system
- Unique Neutrik chuck-type strain relief
- Color coding with accessory BXX-* - to garantee IP65 protection, boot has to be mounted with metal ring of NE8MC6-MO
| SKU | NE8MC6-MO |
|---|---|
| Vekt (kg) | 0.050000 |
| Enhet | Stk |
| Fabrikant | Neutrik |
| Han-/Hunkjønn | Hankjønn |
| Antall poler | 3-pins |
| Farge | Svart |
| CAT Standard | CAT6 |
| IP-grad | IP 65 |
