SKU
MX410LP/C
Shure 10-inch gooseneck cardioid, less preamp, LED
MX410 overflatemontert versjon er en svanehalsmikrofon med tofarget LED som statusdisplay. Den har en 10" svanehals og passer for styrerom og andre steder hvor estetikk er viktig.
veil. inkl. MVA. veil eks. MVA
Din pris per Stk Veil. per Stk inkl. mva. eks. MVA.
Kontakt vår ekspert om dette produktet
MX410 overflatemontert versjon er en svanehalsmikrofon med tofarget LED som statusdisplay. Den har en 10" svanehals og passer for styrerom og andre steder hvor estetikk er viktig.
- Svanehals lengde: 10 tommer / 25,4 cm
- Lav profil, estetisk design
- Bredt dynamisk område og jevn frekvensrespons
- RF-filtrering med CommShield™-teknologi
- Statusindikator: Tofarget LED nederst på svanehalsen eller rød lysring på svanehalsoverdelen
- Kapselalternativer: Ingen, Cardioid, Supercardioid
Alternativer for forforsterker
- MX400DP frittstående base for MX405 og MX410 modeller
- MX890 trådløs frittstående base for MX405- og MX410-modeller
- MX400SMP overflatemontert forforsterker for MX405- og MX410-modeller
- MXW8 trådløs frittstående base for MX405, MX410 og MX415 modeller
- ULXD8 trådløs frittstående base for MX405, MX410 og MX415-modeller
I esken:
1 stk RK513WS Snap-fit skum vindhette
1 MX400SMP overflatemontert forforsterker
1 65A2190 Festevingemutter
2 66A405 Gummiisolasjonsringer
1 95A2529 5-pins XLR hunnkontakt
Oversikt over de ulike variantene av MX405, MX410, og MX415
| Family | SKUs | Patterns | Length | LED at Top | LED at Base | Color | DualFlex | Preamp Incl. |
|---|---|---|---|---|---|---|---|---|
| MX405 | MX405 | /C, /S, /MS, /N | 5" | None | Red/Green | Black | No | MX400SMP |
| MX405R | /C, /S, /MS, /N | 5" | Red | None | Black | No | MX400SMP | |
| MX405LP | /C, /S, /MS, /N | 5" | None | Red/Green | Black | No | None | |
| MX405RLP | /C, /S, /MS, /N | 5" | Red | None | Black | No | None | |
| MX405WLP | /N | 5" | None | Red/Green | White | No | None | |
| MX405WRLP | /N | 5" | Red | None | White | No | None | |
| MX410 | MX410 | /C, /S, /MS, /N | 10" | None | Red/Green | Black | No | MX400SMP |
| MX410R | /C, /S, /MS, /N | 10" | Red | None | Black | No | MX400SMP | |
| MX410LP | /C, /S, /MS, /N | 10" | None | Red/Green | Black | No | None | |
| MX410RLP | /C, /S, /MS, /N | 10" | Red | None | Black | No | None | |
| MX410LPDF | /C, /S, /MS, /N | 10" | None | Red/Green | Black | Yes | None | |
| MX410RLPDF | /C, /S, /MS, /N | 10" | Red | None | Black | Yes | None | |
| MX410WLP | /N | 10" | None | Red/Green | White | No | None | |
| MX410WRLP | /N | 10" | Red | None | White | No | None | |
| MX410WLPDF | /N | 10" | None | Red/Green | White | Yes | None | |
| MX410WRLPDF | /N | 10" | Red | None | White | Yes | None | |
| MX415 | MX415 | /C, /S, /MS, /N | 15" | None | Red/Green | Black | No | MX400SMP |
| MX415R | /C, /S, /MS, /N | 15" | Red | None | Black | No | MX400SMP | |
| MX415LP | /C, /S, /MS, /N | 15" | None | Red/Green | Black | No | None | |
| MX415RLP | /C, /S, /MS, /N | 15" | Red | None | Black | No | None | |
| MX415LPDF | /C, /S, /MS, /N | 15" | None | Red/Green | Black | Yes | None | |
| MX415RLPDF | /C, /S, /MS, /N | 15" | Red | None | Black | Yes | None | |
| MX415WLP | /N | 15" | None | Red/Green | White | No | None | |
| MX415WRLP | /N | 15" | Red | None | White | No | None | |
| MX415WLPDF | /N | 15" | None | Red/Green | White | Yes | None | |
| MX415WRLPDF | /N | 15" | Red | None | White | Yes | None |
| Type | Condenser (electret bias) |
|---|---|
| Frequency Response | 50–17000 Hz |
| Polar Pattern (at 1 kHz) | MX405/C, MX410/C: Cardioid MX405/S, MX410/S: Supercardioid |
| Output Impedance | EIA Rated at 150 Ω (170 Ω actual) |
| Output Configuration | Active Balanced |
| Sensitivity (at 1 kHz , open circuit voltage) | Cardioid: –35 dBV/Pa (18 mV) Supercardioid: –34 dBV/Pa (21 mV) 1 Pascal=94 dB SPL |
| Maximum SPL (1 kHz at 1% THD, 1 kW load) | Cardioid: 121 dB Supercardioid: 120 dB |
| Equivalent Output Noise (A-weighted) | Cardioid: 28 dB SPL Supercardioid: 27 dB SPL |
| Signal-to-Noise Ratio (referenced at 94 dB SPL at 1 kHz) |
Cardioid: 66 dB Supercardioid: 68 dB |
| Dynamic Range (1 kΩ load at 1 kHz) | 93 dB |
| Common Mode Rejection (10 Hz to 100 kHz) | 45 dB minimum |
| Preamplifier Output Clipping Level (1% THD) | -8 dBV (0.4 V) |
| Polarity 3-Pin XLR: | Positive sound pressure on diaphragm produces positive voltage on pin 2 /relative to pin 3 of output XLR connector. 5-Pin XLR: Positive sound pressure on diaphragm produces positive voltage on pin 4 relative to pin 2 of output XLR connector. |
| Weight | MX405: 0.054 kg (0.119 lbs) MX410: 0.068 kg (0.150 lbs) MX400DP: 0.516 kg (1.138 lbs) MX400SMP (w/ Kit): 0.125 kg (0.275 lbs) |
| Logic Connections | LED IN: Active low (≤1.0V), TTL compatible. Absolute maximum voltage: -0.7V to 50V. LOGIC OUT: Active low (≤1.0V), sinks up to 20mA, TTL compatible. Absolute maximum voltage: -0.7V to 50V (up to 50V through 3kΩ). |
| Mute Switch Attenuation | -50 dB minimum |
| Cable | MX400DP: 6.1 m (20 ft) attached cable with shielded audio pair terminated at a 3-pin male XLR and three unterminated conductors for logic control |
| Environmental Conditions | Operating Temperature: -18–57 °C (0–135 °F) Storage Temperature: -29–74 °C (-20–165 °F) Relative Humidity: 0–95% |
| Power Requirements | 48–52 Vdc phantom, 8.0 mA |
| SKU | MX410LP/C |
|---|---|
| Vekt (kg) | 0.471000 |
| Enhet | Stk |
| EAN | 042406141383 |
| Fabrikant | Shure |
| Produktserie | Microflex |
| Mikrofonhode | Kondensator |
| Mikrofon Karakteristikk | Kardioid |
| Type | Svanehals |
| Farge | Svart |
