Shure GLXD2+ SM58 HANDHELD TRANSMITTER

Name: Shure GLXD2+ SM58 HANDHELD TRANSMITTER
Price: 4695 NOK
Availability: InStock

veil. inkl. MVA. veil eks. MVA

Din pris per Stk Veil. per Stk inkl. mva. eks. MVA.

Kontakt vår ekspert om dette produktet

System Specifications

Compatibility	With Frequency Manager: Up to 11 compatible systems in typical setting, and up to 16 under ideal conditions Without Frequency Manager: Up to 4 compatible systems in typical setting, and up to 8 under ideal conditions
System Operating Range	Indoors: Up to 30 m (100 ft.) typical, with a maximum of 60 m (200 ft.) under ideal conditions Outdoors: Up to 20 m (65 ft.) typical, with a maximum of 50 m (165 ft.) under ideal conditions
Transmit Mode	Shure Proprietary Digital - Dual Band (2.4 GHz and 5.8 GHz)
Audio Frequency Response	20 Hz – 20 kHz Note: Dependent on microphone type
Dynamic Range	120 dB, A-weighted
RF Sensitivity	-88 dBm, typical
Total Harmonic Distortion	0.07%, typical
RF Output Power	10 mW E.I.R.P. max
Operating Temperature Range	-18°C (0°F) to 57°C (135°F) Note: Battery characteristics may limit this range.
Storage Temperature Range	-29°C (-20°F) to 74°C (165°F)
Polarity	Positive pressure on microphone diaphragm (or positive voltage applied to tip of WA302 phone plug) produces positive voltage on pin 2 (with respect to pin 3 of low-impedance output) and the tip of the high impedance 6,35 mm output.
Battery Life	Up to 12 hours
NOTE: All Specifications are subject to change. Performance may vary depending on country regulations and operating environment.

GLXD2+ DUAL BAND HANDHELD TRANSMITTER

DIMENSIONS
	Model	A	B	C
	SM58	51 mm, 2.0 in.	246mm, 9.9 in.	37 mm, 1.5 in.
	BETA 58	51 mm, 2.0 in.	246mm, 9.9 in.	37 mm, 1.5 in.
	BETA87A	51 mm, 2.0 in.	246mm, 9.9 in.	37 mm, 1.5 in.
WEIGHT
&nsbp;	SM58	275 g (9.7 oz), without battery
	BETA 58	BETA 58 - 225 g (7.9 oz), without battery
	BETA87A	BETA 87A - 265 g (9.3 oz), without battery
Housing	Aluminum alloy, ABS plastic
Power Requirements	3.6 V Rechargeable Li-Ion
RF Output Power	10 mW E.I.R.P. max
Maximum Input Level	146 dB SPL
