SKU
GLXD2+/SM58=-Z4
Shure GLXD2+ SM58 HANDHELD TRANSMITTER
veil. inkl. MVA. veil eks. MVA
Din pris per Stk Veil. per Stk inkl. mva. eks. MVA.
Kontakt vår ekspert om dette produktet
System Specifications |
|
|---|---|
|
|
|
| Compatibility | With Frequency Manager: Up to 11 compatible systems in typical setting, and up to 16 under ideal conditions Without Frequency Manager: Up to 4 compatible systems in typical setting, and up to 8 under ideal conditions |
| System Operating Range | Indoors: Up to 30 m (100 ft.) typical, with a maximum of 60 m (200 ft.) under ideal conditions Outdoors: Up to 20 m (65 ft.) typical, with a maximum of 50 m (165 ft.) under ideal conditions |
| Transmit Mode | Shure Proprietary Digital - Dual Band (2.4 GHz and 5.8 GHz) |
| Audio Frequency Response | 20 Hz – 20 kHz Note: Dependent on microphone type |
| Dynamic Range | 120 dB, A-weighted |
| RF Sensitivity | -88 dBm, typical |
| Total Harmonic Distortion | 0.07%, typical |
| RF Output Power | 10 mW E.I.R.P. max |
| Operating Temperature Range | -18°C (0°F) to 57°C (135°F) Note: Battery characteristics may limit this range. |
| Storage Temperature Range | -29°C (-20°F) to 74°C (165°F) |
| Polarity | Positive pressure on microphone diaphragm (or positive voltage applied to tip of WA302 phone plug) produces positive voltage on pin 2 (with respect to pin 3 of low-impedance output) and the tip of the high impedance 6,35 mm output. |
| Battery Life | Up to 12 hours |
| NOTE: All Specifications are subject to change. Performance may vary depending on country regulations and operating environment. | |
GLXD2+ DUAL BAND HANDHELD TRANSMITTER |
||||
|---|---|---|---|---|
|
|
||||
| DIMENSIONS | ||||
| Model | A | B | C | |
| SM58 | 51 mm, 2.0 in. | 246mm, 9.9 in. | 37 mm, 1.5 in. | |
| BETA 58 | 51 mm, 2.0 in. | 246mm, 9.9 in. | 37 mm, 1.5 in. | |
| BETA87A | 51 mm, 2.0 in. | 246mm, 9.9 in. | 37 mm, 1.5 in. | |
| WEIGHT | ||||
| &nsbp; | SM58 | 275 g (9.7 oz), without battery | ||
| BETA 58 | BETA 58 - 225 g (7.9 oz), without battery | |||
| BETA87A | BETA 87A - 265 g (9.3 oz), without battery | |||
| Housing | Aluminum alloy, ABS plastic | |||
| Power Requirements | 3.6 V Rechargeable Li-Ion | |||
| RF Output Power | 10 mW E.I.R.P. max | |||
| Maximum Input Level | 146 dB SPL | |||
| SKU | GLXD2+/SM58=-Z4 |
|---|---|
| Vekt (kg) | 0.587000 |
| Enhet | Stk |
| EAN | 042406720311 |
| Fabrikant | Shure |
| Produktserie | GLXD+ |
| Produkttype | Trådløs sender |
| Mikrofonhode | Dynamisk Kardioid mikrofon |
| Mikrofon Karakteristikk | Kardioid |
| Frekvensområde | 2.4 / 5.8 GHz |
| Antall kanaler | 1 kanal |
| Farge | Svart |
