Shure MXA310 TABLE ARRAY,INTELLIMIX,WHT

Audio Capture / DSP

Up to four simultaneous polar patterns including the innovative “toroid” pattern, capturing audio from table level while rejecting unwanted overhead artifacts (additional patterns include Omnidirectional, Cardioid, Supercardioid, Hypercardioid, and Bidirectional—all steerable to any angle in 15 degree increments)

IntelliMix DSP Suite

• Steerable Coverage Technology
• Automatic Mixing
• 4 Band C/S PEQ assignable to any one channel at a time

Software Control

Browser-based control software that features a simple yet smart interface showing templates and varying polar patterns for all device parameters

Stores 10 presets

  ,

Connectivity

Dante Audio Networking, standard PoE (class 0), and Control carried on single Ethernet cable

Control strings for third-party preset controllers including Crestron and AMX

  ,

Hardware / Installation

Configurable multi-color LED

• Displays Mute and Unmute status in Ring, Segment or Automix in two colors (available in red, orange, yellow, green, blue, purple, white, pink)
• Brightness controls (default, dim, disabled)

Mute Switch modes

• Toggle, Push-to-Talk, Push-to-Mute, Disable
• Backlit LED indicator of enabled/disabled mute switch
• Generates external control signal to mute a downstream device or trigger camera presets

  ,

CommShield® RF Immunity (learn more in our blog post)

Cable exit along or through table allows for easy retrofitting of previous Shure MX396/MX395 boundary microphone installations

Device Reboot/Factory Reset Options

• Two stage hardware reset: 4 second press resets network settings, 8 second press resets to factory default restoring all settings including device name and network details

Frequency Response: Flat

Form Factor: Desktop

Applications: Conferencing

Polar Pattern: Switchable Toroid

Microphone Type: Array

Model Line: Microflex Advance

  ,
