SKU
MXA710B-2FT
Shure MXA710 LINEAR ARRAY,BLK,2 FEET (60CM)
Pris på forespørsel
Kontakt vår ekspert om dette produktet
Shure Systems Norge
Arild Høyem
+47 970 55 960 | ah@benum.com
Tore Vidar Knutsmoen
+47 970 55 974 | tvk@benum.com
MXA710 Linear Array-mikrofon representerer den neste utviklingen innen Shure array-mikrofonteknologi, designet for lydopptak av høy kvalitet i førsteklasses AV-konferansemiljøer. Den slanke, lineære formfaktoren til MXA710 sørger for enkel plassering praktisk talt hvor som helst i et møteområde, inkludert på en vegg, rundt et display, tak eller i et konferanserom. MXA710 er tilgjengelig i to lengder og tre farger og inkluderer proprietær Shure IntelliMix® DSP og Autofocus -teknologi som gir all prosessering som trengs for ekko- og støyfri konferanselyd.
General | ||
---|---|---|
All specifications measured from narrow lobe width. Values for all widths are within ± 3 dB of these specifications unless otherwise noted. | ||
Lobe Width | ||
Adjustable | Narrow | 30 degrees |
Medium | 40 degrees | |
Wide | 70 degrees | |
Connector Type | ||
RJ45 | ||
Power Requirements | ||
Power over Ethernet (PoE), Class 0 | ||
Power Consumption | ||
10 W maximum | ||
Weight | ||
MXA710-2FT | 2 lbs (0.91 kg) | |
MXA710-4FT | 3.7 lbs (1.67 kg) | |
Product Dimensions | ||
MXA710-2FT | 0.87 x 2.36 x 25.04 in. (22.09 x 60 x 636 mm) H x W x L | |
MXA710-4FT | 0.87 x 2.36 x 49.12 in. (22.09 x 60 x 1247.76 mm) H x W x L | |
Control Software | ||
Shure Designer | ||
Plenum Rating | ||
UL2043 (Suitable for Air Handling Spaces) | ||
Dust Protection | ||
IEC 60529 IP5X Dust Protected | ||
Operating Temperature Range | ||
-6.7°C (20°F) to 40°C (104°F) | ||
Storage Temperature Range | ||
-29°C (-20°F) to 74°C (165°F) | ||
Audio | ||
Frequency Response | 100 Hz to 20 kHz | |
AES67 or Dante Digital Output | ||
Channel Count | MXA710-2FT | 6 total channels (4 independent transmit channels, 1 Automix output, 1 AEC reference in channel) |
MXA710-4FT | 10 total channels (8 independent transmit channels, 1 Automix output, 1 AEC reference in channel) | |
Sampling Rate | 48 kHz | |
Bit Depth | 24 | |
Sensitivity at 1 kHz | ||
MXA710-2FT | -7.4 dBFS/Pa | |
MXA710-4FT | -7.9 dBFS/Pa | |
Maximum SPL Relative to 0 dBFS overload | ||
MXA710-2FT | 101.4 dB SPL | |
MXA710-4FT | 101.9 dB SPL | |
Signal-To-Noise Ratio Ref. 94 dB SPL at 1 kHz | ||
71.2 dB A-weighted | ||
Latency Does not include Dante latency | ||
Direct Outputs | 8.7 ms | |
Automix output (Includes IntelliMix processing) | 19.3 ms | |
Self Noise | ||
MXA710-2FT | 22.9 dB SPL-A | |
MXA710-4FT | 22.8 dB SPL-A | |
Dynamic Range | ||
MXA710-2FT | 78.5 dB | |
MXA710-4FT | 79.1 dB | |
Built-in Digital Signal Processing | ||
Automatic mixing, Acoustic Echo Cancellation (AEC), Noise Reduction, Automatic Gain Control, Compressor, Delay, Equalizer (4-band Parametric), Mute, Gain (140 dB range) | ||
Acoustic Echo Cancellation Tail Length | ||
Up to 250 ms | ||
Networking | ||
Cable Requirements | Cat 5e or higher (shielded cable recommended) |
SKU | MXA710B-2FT |
---|---|
Vekt (kg) | 1.896000 |
Enhet | Stk |
EAN | 042406571401 |
Fabrikant | Shure |
Produktserie | Microflex Advance |
Type | Array |
Farge | Svart |
MXA710 Linear Array-mikrofon representerer den neste utviklingen innen Shure array-mikrofonteknologi, designet for lydopptak av høy kvalitet i førsteklasses AV-konferansemiljøer. Den slanke, lineære formfaktoren til MXA710 sørger for enkel plassering praktisk talt hvor som helst i et møteområde, inkludert på en vegg, rundt et display, tak eller i et konferanserom. MXA710 er tilgjengelig i to lengder og tre farger og inkluderer proprietær Shure IntelliMix® DSP og Autofocus -teknologi som gir all prosessering som trengs for ekko- og støyfri konferanselyd.
General | ||
---|---|---|
All specifications measured from narrow lobe width. Values for all widths are within ± 3 dB of these specifications unless otherwise noted. | ||
Lobe Width | ||
Adjustable | Narrow | 30 degrees |
Medium | 40 degrees | |
Wide | 70 degrees | |
Connector Type | ||
RJ45 | ||
Power Requirements | ||
Power over Ethernet (PoE), Class 0 | ||
Power Consumption | ||
10 W maximum | ||
Weight | ||
MXA710-2FT | 2 lbs (0.91 kg) | |
MXA710-4FT | 3.7 lbs (1.67 kg) | |
Product Dimensions | ||
MXA710-2FT | 0.87 x 2.36 x 25.04 in. (22.09 x 60 x 636 mm) H x W x L | |
MXA710-4FT | 0.87 x 2.36 x 49.12 in. (22.09 x 60 x 1247.76 mm) H x W x L | |
Control Software | ||
Shure Designer | ||
Plenum Rating | ||
UL2043 (Suitable for Air Handling Spaces) | ||
Dust Protection | ||
IEC 60529 IP5X Dust Protected | ||
Operating Temperature Range | ||
-6.7°C (20°F) to 40°C (104°F) | ||
Storage Temperature Range | ||
-29°C (-20°F) to 74°C (165°F) | ||
Audio | ||
Frequency Response | 100 Hz to 20 kHz | |
AES67 or Dante Digital Output | ||
Channel Count | MXA710-2FT | 6 total channels (4 independent transmit channels, 1 Automix output, 1 AEC reference in channel) |
MXA710-4FT | 10 total channels (8 independent transmit channels, 1 Automix output, 1 AEC reference in channel) | |
Sampling Rate | 48 kHz | |
Bit Depth | 24 | |
Sensitivity at 1 kHz | ||
MXA710-2FT | -7.4 dBFS/Pa | |
MXA710-4FT | -7.9 dBFS/Pa | |
Maximum SPL Relative to 0 dBFS overload | ||
MXA710-2FT | 101.4 dB SPL | |
MXA710-4FT | 101.9 dB SPL | |
Signal-To-Noise Ratio Ref. 94 dB SPL at 1 kHz | ||
71.2 dB A-weighted | ||
Latency Does not include Dante latency | ||
Direct Outputs | 8.7 ms | |
Automix output (Includes IntelliMix processing) | 19.3 ms | |
Self Noise | ||
MXA710-2FT | 22.9 dB SPL-A | |
MXA710-4FT | 22.8 dB SPL-A | |
Dynamic Range | ||
MXA710-2FT | 78.5 dB | |
MXA710-4FT | 79.1 dB | |
Built-in Digital Signal Processing | ||
Automatic mixing, Acoustic Echo Cancellation (AEC), Noise Reduction, Automatic Gain Control, Compressor, Delay, Equalizer (4-band Parametric), Mute, Gain (140 dB range) | ||
Acoustic Echo Cancellation Tail Length | ||
Up to 250 ms | ||
Networking | ||
Cable Requirements | Cat 5e or higher (shielded cable recommended) |
SKU | MXA710B-2FT |
---|---|
Vekt (kg) | 1.896000 |
Enhet | Stk |
EAN | 042406571401 |
Fabrikant | Shure |
Produktserie | Microflex Advance |
Type | Array |
Farge | Svart |
