CM-CU1 Commentator Unit 1 Commentator & , Line Input
The CM-CU1 offers the same high quality, robust specification as the CM-CU21, with a feature set tailored to single commentator applications.Features of the CM-CU1 Commentator Unit
- Commentator position with individual output , plus main mix output.
- Line input with configurable output and headphone presence.
- Talkback outputs selectable by the commentator, with built in limiter and adjustable gain.
- 5 Return audio circuits that are routed to headphones along with the commentator input. Any source can be individually level controlled and sent to left, right or both ears.
- A wide input gain range and switchable phantom power allows support of a variety of microphone types including low output ribbon, headsets and high output phantom powered microphones.
- User preset adjustable limiter on main output with limit activity indication.
- Built in line-up tone for initial cabling checks.
- 21 Segment LED PPM meter showing main output level.
- Transformer balanced inputs and outputs.
- Fitted formica Sharpie designation strips.
- Robust mechanical design with protection for potentiometer knobs.
- Universal AC mains, or 12-24 volt DC power.
Technical Specification For CM-CU1 | |
Microphone Input | |
| Gain Range: | +20dB to +86dB |
| Maximum Input Level: | -6dBu |
| Equivalent Input Noise: | 130dB Ref. 80dB gain with 150? termination |
| Equivalent Input Noise: | 128dB Ref. 50dB gain with 150? termination |
| C.M.R.R. | > ,60dB |
| Frequency Response: | ±0.5dB 20Hz to 22kHz Ref 50dB gain @ 1kHz |
| , | , |
Electronically Balanced Line Input | |
| Gain Range: | -83dB to +10dB |
| Maximum Input Level: | +25dBu |
| C.M.R.R. | > ,70dB |
| Frequency Response: | ±0.2dB 20Hz to 22kHz Ref 0dBu @ 1kHz |
| , | , |
Transformer Balanced Monitor Inputs | |
| Gain Range: | -66dB to +11dB measured @ Headphone output |
| Maximum Input Level: | +21dBu |
| C.M.R.R. | > ,55dB |
| Frequency Response: | ±0.5dB 20Hz to 22kHz Ref 0dBu @ 1kHz |
| , | , |
Transformer Balanced Mix Output | |
| Maximum Output Level (Limiter Off): | +24dBu |
| Frequency Response: | ±0.5dB 20Hz to 22kHz Ref 0dBu @ 1kHz |
| Noise: | -94dB Average weighting Ref +8dBu |
| THD & , N: | < ,0.02% Ref. 1kHz @ +8dBu |
| THD & , N: | < ,0.065% Ref. 1kHz @ +18dBu |
| 1% Distortion Point: | +18dBu @ 24Hz |
| , | , |
Transformer Balanced Talkback Outputs | |
| Maximum Output Level Limited: | +8dBu |
| Frequency Response: | ±0.5dB 20Hz to 22kHz Ref 0dBu @ 1kHz |
| Noise: | -94dB Average weighting Ref +8dBu |
| THD & , N: | < ,0.02% Ref. 1kHz @ +8dBu |
| Gain Adjustment: | 0dB to +12dB |
| , | , |
Electronically Balanced Comm Output | |
| Maximum Output Level: | +25dBu |
| Frequency Response: | ±0.2dB 20Hz to 22kHz Ref 0dBu @ 1kHz |
| Noise: | -98dB Average weighting Ref+8dBu |
| THD & , N: | < ,0.002% Ref. 1kHz @ +8dBu |
| , | , |
Headphone Output | |
| Gain Range: | -66dB to +11dB |
| Maximum Output Level: | +19dBu |
| Frequency Response: | ±0.5dB 20Hz to 22kHz Ref 0dBu @ 1kHz |
| Noise: | -85dB Average weighting Ref +8dBu |
| THD & , N: | < ,0.005% Ref. 1kHz @ +8dBu |
| , | , |
Main Panel Operational Controls & , Indicators | |
| On-Air , Button: | Illuminated button with latching action |
| Talkback A, B, C & , D Buttons: | Illuminated buttons with selectable momentary and/or latching action |
| Headphone Monitor Controls: | Input source level adjustment potentiometers Headphone channel selection switches |
| Line Input Level: | line input mode level potentiometer |
| PPM Meter: | 21 segment display showing mix output level, brightness level Is selectable |
| Limit LED: | Indicates main output limiter is active, colour & , brightness level is selectable |
| Power LED: | Indicates operating mode , normal or setup |
| , | , |
Front Panel Operational Controls | |
| Phantom: | Switch to enable 48V microphone phantom power |
| , | , |
| Mic Gain: | Microphone gain potentiometer and range select switch selects +20dB to +56dB or +50 to +86dB |
| , | , |
Rear Panel Operational Controls | |
| On Air Lock: | Switch to prevent On Air control from being deactivated Momentary push-button to override on air lock |
| T/B Gang: | Switch to link operation of talkbacks A, B, C & , D |
| T/B Gain: | 0dB to +12dB |
| Limiter: | Switch to enable limiter on mix output Limit level adjustment potentiometer |
| Test Tone: | Switch to enable 1 kHz line-up tone |
| , | , |
Configuration Options – Accessible via Setup Mode | |
| On Air Control Mode: | Disabled, normal or permanently on |
| Talkback Button Action: | Momentary, latching or both |
| Headphone Routing: | Line-level input permanently routed/routed if on air to Commentator headphones Commentator input permanently routed/not routed to headphone monitors |
| Line Level Input Routing: | Line-level input permanently routed/not routed/routed if on air to main output |
| Display Preferences: | Limit LED colour and brightness Button LED brightness PPM meter LED brightness/disable |
| Permanent Option Backup: | Save/load options to/from Permanent backup or return to factory defaults |
| , | , |
Front Panel Connections | |
| Headphone Output: | 1 x locking headphone jack socket |
| Microphone Input: | 1 x XLR-3 pin latching female |
| Line Input: | 1 x XLR-3 pin latching female |
| , | , |
Rear Panel Connections | |
| Prog, A, B, C & , D Inputs: | 5 x XLR-3 pin female (transformer balanced) |
| Comm Output: | 1 x XLR-3 pin male (electronic balanced) |
| Talkback A, B, C & , D Outputs: | 4 x XLR-3 pin male (transformer balanced) |
| Mix Output: | 1 x XLR-3 pin male (transformer balanced) |
| GPIO Port: | 15-way ‘D’-type socket |
| Mains Input: | Universal filtered IEC, continuously rated 85-264VAC, 47-63Hz, 10W |
| Fuse Rating: | Anti-surge fuse 1A 20 x 5mm |
| DC Input: | XLR-4 pin male 12V DC, 650mA Typical, 850mA Maximum 24V DC, 325mA Typical, 425mA Maximum |
| Earth Point: | M4 stud. |
| , | , |
Equipment Type | |
| CM-CU1 | Commentator Unit, 1 Presenter |
| , | , |
Physical Specification | |
| Dimensions (Raw): | 270mm (W) x 230mm (D) x 70mm (H - front) x 95mm (H - rear) 10.6” (W) x 9” (D) x 2.8” (H - front) x 3.7” (H - rear) |
| Dimensions (Boxed): | 380mm (W) x 350mm (D) x 200mm (H) 15” (W) x 13.8” (D) x 7.8” (H) |
| Weight: | Nett: 3.3kg Gross: 4.3kg Nett: 7.3lbs Gross: 9.4lbs |
| , | , |
Accessories | |
| CM-CUTC | Commentator Unit Transport Case |
| Dimensions(Raw): | 530mm (W) x 210mm (D) x 415mm (H) 20.9” (W) x 8.3” (D) x 16.3” (H) |
| Dimensions (Boxed): | 600mm (W) x 260 (D) x 420 (H) 23.6” (W) x 10.2” (D) x 16.5” (H) |
| Weight: | Net: 4.0kg Gross: 5.0kg Net: 8.8lbs Gross: 11.0lbs |
| SKU | CM-CU1 |
|---|---|
| Vekt (kg) | 0.050000 |
| Enhet | Stk |
| Fabrikant | Sonifex |
| Produktserie | Talkback, IFB & Commentary |
| Tilkobling | XLR, Jack |
