AVN-GMCS IEEE1588 PTP Grandmaster Clock with GPS Receiver
The AVN-GMCS is a PTPv2 grandmaster clock for use with AoIP applications. IEEE1588-2008 PTPv2 (precision time protocol) is used to synchronise all the nodes within a network. To achieve this one of the nodes must become the master clock and distribute time packets to the others. The AVN-GMCS is designed to perform this role simply and accurately, enabling sub micro second synchronisation between all nodes.Features:
- AES67/RAVENNA/AES-R16 compatible.
- GPS satellites received indicator.
- Master and slave sync modes.
- 8ns PTPv2 time stamping resolution.
- Holdover drift < ,1ppm, with options for < ,0.01ppm & , < ,0.0005ppm.
- AES-3id, wordclock & , variable PPS outputs.
- Analogue master input.
- Dual power supply inputs.
- Front panel display.
- GPS sync and power supply present LED indicators.
- Real time clock for accurate date/time.
- Responsive design Ethernet webserver and front panel control & , configuration.
Technical Specification For AVN-GMC | |
Timing Specification | |
| Profile Support: | Default (RAVENNA), Media (AES67), AES-R16-2016 (SMPTE-ST 2059-2 & , AES67 compatible), Custom profile |
| Timing Protocol: | PTPv2, IEEE1588-2008 |
| Timing Accuracy: | PTP time stamping resolution 8ns |
| Holdover Drift: TCXO: OCXO: CSAC: | < ,90ms < ,900µs < ,45µs These figures are over 24 hours at constant temperature |
| GPS Performance: GPS Frequency: | 50 channel GPS receiver 1575.42MHz, L1 band |
| , | , |
Clock Specification | |
| Input Impedance: | 75O |
| Output Impedance: | < ,75O |
| Antenna Impedance: | 50O |
| , | |
Connections | |
| Clocking Input: | BNC female |
| Clocking Outputs: | 3 x BNC female Wordclock, AES-3id @ 32, 44.1, 48, 96, 176.4 & , 192kHz Variable PPS (1, 10, 100, 1000) TTL |
| GPS Input: | SMA socket |
| GPIO: | D-Type female 9 way |
| Ethernet Port: | RJ45 socket, 100 BASE-T |
| Mains AC Input: | Universal filtered IEC socket, continuously rated 85-264 VAC @47-63Hz, max 10W |
| DC Input: Maximum Operating Range (DC): | 1 x 12V, KPJX-45 socket, positive pins 1 and 3 10.3V to 13.2V DC |
| , | , |
Equipment Type | |
| AVN-GMCS: | Grandmaster clock for PTP systems, GPS, IP, TCXO, 1ppm, rackmount |
| AVN-GMCOS: | Grandmaster clock for PTP systems, GPS, IP, OCXO, 0.01ppm, rackmount |
| AVN-GMCCS: | Grandmaster clock for PTP systems,GPS, IP, CSAC, 0.0005ppm rackmount |
| , | , |
Physical Specification | |
| Dimensions: (Raw) | 4.4cm (H) x 48.3cm (W) x 17.8cm (D(1U) 1.8” (H) x 19” (W) x 7” (D) (1U) |
| Dimensions (Boxed): | 6.8cm (H) x 58.8cm (W) x 27cm (D) 2.7” (H) x 23” (W) x 10.6” (D) |
| Weight: | Nett: 1.5kg , ,Gross: 2.2kg Nett: 3.2lbs ,Gross: 4.8lbs |
Accessories | |
| AVN-DC150: | 150W DC power supply with KPJX-4S plug |
