Universal Audio Apollo X8, x4 Mic x6 DSP, TB3

Apollo x8 , x6 DSP Prosessering med 4 stk Unison™ mik preamp og 2 stk Hi-Z innganger for opptak med emuleringer av klassiske preamp fra Neve, API og Universal Audio. Nytt og forbedret frontpanel med talkback mik, støtte for 7.1 monitoring ut, totalt 18 inn/24 ut

veil. inkl. MVA. veil eks. MVA

Din pris per Stk Veil. per Stk inkl. mva. eks. MVA.

Kontakt vår ekspert om dette produktet

Ove Horpestad

Ove er merkevareansvarlig for Genelec, Universal Audio og ZOOM.

oh@benum.com +47 970 55 943 send e-post

Gå til slutten av bildegalleri

Gå til begynnelsen av bildegalleri

Beskrivelse

Når Apollo lydkortene ble lansert i 2012 tok det markedet med storm og solgte mer enn alle andre interface i sin klasse og ble meget godt mottatt av brukere over hele verden. Apollo satte en ny standard og skapte en ny kategori innenfor profesjonelle lydkort.
Apollo sine unike funksjoner som sanntid UAD prosessering, Unison (preamp modellering) og høykvalitets lydkonvertering har gjort at den til studiostandard verden over. Med sin unike DSP teknologi er det mulig med å kjøre plugins uten forsinkelse i monitoring og emulering av preamper og plugins fra blant annet Neve, API, SSL med flere.

Nå presenterer UA sin tredje generasjon av Apollo.

Universal Audio sine nye ApolloX Thunderbolt 3 lydkort for mac og PC kommer med bedre ADDA konvertering, nye monitoreringsfunksjoner med støtte for opptil 7.1. Det kan seriekobles opptil 4 Apollo enheter via Thunderbolt for mer I/O og UAD DSP kraft, alt pakket inn i en lekker ny mørk grå utseende. Nye ApolloX setter igjen en ny standard!

Nye Apollo serien tilbyr:

Ny generasjon ADDA konvertering, nå enda bedre enn nåværende generasjon av Apollo.
Alle i ApolloX serien har nå 6 stk UAD-2 DSP gjør det mulig med sanntid UAD prosessering gjør opptak med plug-ins fra Lexicon, Studer, Manley, Ampex, UA, med flere uten forsinkelse. Det er nå en portefølje på over 100 plugins å velge mellom.
Unison mik preamper og Hi-Z innganger (Apollo X6, X8 og X8P) for opptak med emuleringer av klassiske mik pre fra Neve, API, SSL, UA mf. ApolloX har nå også støtte +24dBu.
ApolloX med Thunderbolt 3 tillater seriekobling av opptil 4 Apollo enheter over Thunderbolt 3. Totalt kan opptil 6 enheter i Apollo/UAD-2 serien seriekobles til et stort system.
Plugin som er inkludert er: Classics Plus Bundle: UAD plug-in bundel med 610-B Rør Preamp og EQ, Legacy LA-2A, 1176 og Fairchild kompressor, Pultec EQ, gitar og bass amp emuleringer fra Marshall og Ampeg mm.

Apollo x8, m. x6 DSP Prosessering, 4 stk Unison mik preamp og 2 stk Hi-Z innganger for opptak med emuleringer av klassiske preamp fra Neve, API og Universal Audio. Nytt og forbedret frontpanel med talkback mik, støtte for 7.1 monitoring ut, totalt 18 inn/24 ut.

Apollo X6, X8, X8P	Apollo Heritage Edition Rackmount
Analog Realtime Classics Plus	Analog Realtime Classics Plus	Heritage Edition
UA 610-B UA 1176LN Legacy UA 1176SE Legacy Ampeg SVT-VR Classic Fairchild 670 Legacy Marshall Plexi Classic Precision Channel Strip Precision Reflection Engine Precision Delay Mod Precision Delay Mod L Precision Enhancer Hz Pultec EQP-1A Legacy Pultec-Pro Legacy Teletronix LA-2A Legacy Raw Distortion RealVerb Pro	UA 610-B UA 1176LN Legacy UA 1176SE Legacy Ampeg SVT-VR Classic Fairchild 670 Legacy Marshall Plexi Classic Precision Channel Strip Precision Reflection Engine Precision Delay Mod Precision Delay Mod L Precision Enhancer Hz Pultec EQP-1A Legacy Pultec-Pro Legacy Teletronix LA-2A Legacy Raw Distortion RealVerb Pro	Teletronix LA-2A Classic Leveler Collection Pultec Passive EQ Collection 1176 Classic Limiter Collection Pure Plate Reverb UA 610 Tube Preamp & EQ Collection Helios Type 69 Preamp & EQ Collection V76 Preamplifier Oxide Tape Recorder Teletronix LA-3A Audio Leveler Fairchild Tube Limiter Collection

Tekniske spesifikasjoner

SYSTEM
*I/O Complement*
Microphone Inputs	Four
High Impedance (Hi-Z) Instrument Inputs	Two
Analog Line Inputs	Eight
Analog Line Outputs (DC coupled)	Eight (ten including Monitor outputs)
Analog Monitor Outputs (DC coupled)	Two (one stereo pair)
Headphone Outputs	Two stereo
ADAT	Up to eight channels via dual I/O ports with S/MUX
S/PDIF	One stereo input, one stereo output
Thunderbolt 3 Ports	Two
Word Clock	One input, one output
*A/D – D/A Conversion*
Simultaneous A/D conversion	Eight channels
Simultaneous D/A conversion	14 channels
Supported Sample Rates (kHz)	44.1, 48, 88.2, 96, 176.4, 192
Bit Depth Per Sample	24
Analog Round-Trip Latency	1.1 milliseconds @ 96 kHz sample rate
Analog Round-Trip Latency through four UAD legacy plug-ins (included) via Console software	1.1 milliseconds @ 96 kHz sample rate (no additional latency via Realtime UAD Processing)
ANALOG I/O
*Microphone Inputs 1 – 4*
Frequency Response	20 Hz – 20 kHz, ±0.05 dB
Dynamic Range	122 dB (A–weighted)
Total Harmonic Distortion + Noise Ratio (1 kHz @ 4.9 dBu)	-114 dB (0.00020%)
Maximum Input Level (PAD on)	26 dBu
Default Input Impedance	5.4K Ohms (variable via Unison plug-ins)
Gain Range	+10 dB to +65 dB
Pad Attenuation (switchable per input)	20 dB (variable via Unison plug-ins)
Phantom Power	+48V (switchable per mic input)
Connector Type	XLR Female, pin 2 positive
*Hi-Z Inputs 1 – 2*
Frequency Response	20 Hz – 20 kHz, ±0.04 dB
Dynamic Range	121 dB (A–weighted)
Total Harmonic Distortion + Noise Ratio (1 kHz @ 11.2 dBu)	-111 dB (0.00028%)
Maximum Input Level	12.4 dBu
Default Input Impedance	1M Ohms (variable via Unison plug-ins)
Gain Range	+10 dB to +65 dB
Connector Type	¼” Female TS Unbalanced
*Line Inputs 1 – 8*
Frequency Response	20 Hz – 20 kHz, ±0.05 dB
Dynamic Range	123 dB (A–weighted)
Total Harmonic Distortion + Noise Ratio (1 kHz @ 23 dBu)	-113 dB (0.00022%)
Maximum Input Level	24 dBu
Input Impedance	10k Ohms
Gain Range	+10 dB to +65 dB
Connector Type	¼” Female TRS Balanced
*Line Outputs 1 – 8*
Frequency Response	20 Hz – 20 kHz, ±0.07 dB
Dynamic Range	127 dB (A–weighted)
Total Harmonic Distortion + Noise Ratio (1 kHz @ -1 dBFS)	-119 dB (0.00011%)
Maximum Output Level	24 dBu
Output Impedance	100 Ohms
Connector Type	¼” Female TRS Balanced
*Monitor Outputs 1 – 2*
Frequency Response	20 Hz – 20 kHz, ±0.06 dB
Dynamic Range	129 dB (A–weighted)
Total Harmonic Distortion + Noise Ratio (1 kHz @ -1 dBFS)	-118 dB (0.00012%)
Maximum Output Level	24 dBu
Output Impedance	100 Ohms
Connector Type	¼” Female TRS Balanced
*Stereo Headphone Outputs 1 – 2*
Frequency Response	20 Hz – 20 kHz, ±0.05 dB
Dynamic Range	125 dB (A–weighted)
Total Harmonic Distortion + Noise Ratio (1 kHz @ -1 dBFS)	-102 dB (0.00080%)
Maximum Output Power (into 300 ohm load)	150 mW RMS
Connector Type	¼” Female TRS Stereo
DIGITAL I/O
*S/PDIF*
Connector Type	Female Phono (RCA)
Format	IEC 958
Supported Sample Rates (kHz)	44.1, 48, 88.2, 96, 176.4, 192
*ADAT*
Connector Type	Optical TOSLINK JIS F05
Format	ADAT Digital Lightpipe with S/MUX
Supported Sample Rates (kHz)	44.1, 48, 88.2, 96, 176.4, 192
Channel Assignments @ 44.1 kHz, 48 kHz	Port 1 = Channels 1 – 8, Port 2 = 1 – 8 (mirrored)
Channel Assignments @ 88.2 kHz, 96 kHz	Port 1 = Channels 1 – 4, Port 2 = Channels 5 – 8
Channel Assignments @ 176.4 kHz, 192 kHz	Port 1 = Channels 1 – 2, Port 2 = Channels 3 – 4
*Word Clock*
Connector Type	BNC
Lock Range	±4% of any supported sample rate
Word Clock Input Termination	75 Ohms, switchable
ELECTRICAL
Power Supply	External AC-to-DC Power Supply, Level VI compliant
AC Input Connector Type	IEC Male
AC Requirements	100V – 240V AC, 50 – 60 Hz
DC Connector Type	XLR 4-Pin Locking Male (Neutrik P/N NC4MDM3-H)
DC Requirements	12 VDC, 6A
Maximum Power Consumption	72W (30W typical)
ENVIRONMENTAL
Ambient Temperature Range	32º to 104º F (0º to 40º C)
MECHANICAL
*Dimensions*
Width	19 in (48,26 cm)
Height (1U rack space)	1.75 in (4,45 cm)
Depth, Chassis Only	12.125 in (30,80 cm)
Depth, Including Knob & Jack Protrusions	13.5 in (34,29 cm)
Shipping Box (Width x Depth x Height)	23.5 in x 17 in x 7.5 in (59,69 cm x 43,18 cm x 19,05 cm)
*Weight*
Shipping Weight (with box & accessories)	USA: 16.6 lbs (7.52 kg) EU & UK: 16.9 lbs (7.64 kg)
Weight (bare unit)	9 lbs (4.08 kg)
*Package Contents*
Apollo x8 Audio Interface Unit
External Power Supply
AC Power Cable (IEC), Region Specific
Set of (4) Rack-Mount Screws

Attributter

Mer informasjon
SKU	APX8
Vekt (kg)	8.000000
Enhet	Stk
EAN	819937002472
Fabrikant	Universal audio
Produktserie	Apollo
Tilkobling	XLR, Jack, USB-C, S/PDIF, ADAT, Word Clock
