Zoom H5 Handy Recorder

veil. inkl. MVA. veil eks. MVA

Din pris per Stk Veil. per Stk inkl. mva. eks. MVA.

Kontakt vår ekspert om dette produktet

Ove Horpestad

Ove er merkevareansvarlig for Genelec, Universal Audio og ZOOM.

oh@benum.com +47 970 55 943 send e-post

Gå til slutten av bildegalleri

Gå til begynnelsen av bildegalleri

Beskrivelse

Zooms produkter er i stadig utvikling for å tilfredsstille brukernes behov. Den tradisjonen fortsetter med H5.
H5 har 4 spors samtidig opptak. Lik H6 kan den bruke alle de utbyttbare kapslene til Zoom, slik at du kan velge riktig mikrofon til hvert opptak.
H5 gir deg alt du trenger til flerspors opptak, lyd til bilde, høykvalitets podcasting, broadcasting m.m.

H5 har et robust design perfekt for field recording. Den nye X/Y mikrofonkapselen, XYH-5, har to kondensatormikrofoner i shockmount som mimimerer vibrasjoner og håndstøy. ,Kroppen på H5 er utformet slik at den ligger meget godt i ,hånden, og alle funksjoner er lett tilgjengelig. ,

Tekniske spesifikasjoner

General
Recording media:	SD card: 16MB to 2GB , SDHC card: 4GB to ,32GB
Display:	Backlit LCD (128 x 64 ,pixels)
Inputs
INPUTS L/R [XYH-5 X/Y mic]:	Mic type: Unidirectional Sensitivity: -45 dB, 1 kHz at 1 Pa Input gain: -8 to 52 dB Max sound pressure input: 140 dB ,SPL
MIC/LINE IN :	Connector: 1/8" stereo mini jack Input gain: - 8 to 52 dB Input impedance: 2 k O or more Plug-in power: 2.5V supported Backup recording: -12dB lower than set L/R input ,gain
INPUTS 1/2:	Connectors: XLR / TRS combo jacks (XLR: Pin 2 hot / TRS: Tip hot) Input gain (PAD OFF): -8 to 55.0 dB Input gain (PAD ON): -8 to 35.0 dB Input impedance: 1.8 k O or more Max input level: +22 dBu (PAD ON) Phantom power: +12V /+24V /+48V Equivalent Input Noise (EIN): -120 dBu or ,less
Outputs
LINE OUT :	Connector: 1/8" stereo mini jack Rated output level: -10 dBm Output load impedance: 10k O or ,more
PHONE OUT :	Connector: 1/8" stereo mini jack Output Level: 20 W +20 W into 32 O ,load
Built-in speaker:	400mw 8 O ,mono
Recording formats
STEREO MODE:	WAV (BWF-compliant) Sampling frequency: 44.1/48/96 kHz Bit rate: 16/24 (Stereo) Maximum simultaneous recording tracks: ,2 MP3 Sampling frequency: 44.1kHz Bit rate: ,48/56/64/80/96/112/32/160/192/224/256/320kbps
MULTITRACK MODE:	WAV (BWF-compliant) Sampling frequency: 44.1/48 kHz Bit rate: 16/24 (Mono/Stereo) Maximum simultaneous recording tracks: 6 (L/R + INPUT 1/2 + L/R ,backup)
USB
Mass Storage Class operation:	Class: USB 2.0 High ,Speed
Audio Interface operation: Multitrack mode:	Class: USB 2.0 High Speed Sampling frequency: 44.1/48kHz Bit rate: 16/24 bit Inputs / Outputs: 4 / ,2
Audio Interface operation: Stereo mode:	Class: USB 2.0 Full Speed Sampling frequency: 44.1/48kHz Bit rate: 16 bit Inputs / Outputs: 2 / ,2 USB bus powered operation possible (iPad operation supported in Stereo mode ,only)
Power Requirements
	AA size (LR6) battery x 2 AC adapter: AD-17 (DC5V/1A/USB-type) (optional) USB bus ,power

Attributter

Mer informasjon
SKU	H5
Vekt (kg)	0.050000
Enhet	Stk
EAN	4515260013241
Fabrikant	Zoom
Produktserie	Håndholdte opptakere
Farge	Svart
Tilkobling	XLR

Beskrivelse

Tekniske spesifikasjoner

General
Recording media:	SD card: 16MB to 2GB , SDHC card: 4GB to ,32GB
Display:	Backlit LCD (128 x 64 ,pixels)
Inputs
INPUTS L/R [XYH-5 X/Y mic]:	Mic type: Unidirectional Sensitivity: -45 dB, 1 kHz at 1 Pa Input gain: -8 to 52 dB Max sound pressure input: 140 dB ,SPL
MIC/LINE IN :	Connector: 1/8" stereo mini jack Input gain: - 8 to 52 dB Input impedance: 2 k O or more Plug-in power: 2.5V supported Backup recording: -12dB lower than set L/R input ,gain
INPUTS 1/2:	Connectors: XLR / TRS combo jacks (XLR: Pin 2 hot / TRS: Tip hot) Input gain (PAD OFF): -8 to 55.0 dB Input gain (PAD ON): -8 to 35.0 dB Input impedance: 1.8 k O or more Max input level: +22 dBu (PAD ON) Phantom power: +12V /+24V /+48V Equivalent Input Noise (EIN): -120 dBu or ,less
Outputs
LINE OUT :	Connector: 1/8" stereo mini jack Rated output level: -10 dBm Output load impedance: 10k O or ,more
PHONE OUT :	Connector: 1/8" stereo mini jack Output Level: 20 W +20 W into 32 O ,load
Built-in speaker:	400mw 8 O ,mono
Recording formats
STEREO MODE:	WAV (BWF-compliant) Sampling frequency: 44.1/48/96 kHz Bit rate: 16/24 (Stereo) Maximum simultaneous recording tracks: ,2 MP3 Sampling frequency: 44.1kHz Bit rate: ,48/56/64/80/96/112/32/160/192/224/256/320kbps
MULTITRACK MODE:	WAV (BWF-compliant) Sampling frequency: 44.1/48 kHz Bit rate: 16/24 (Mono/Stereo) Maximum simultaneous recording tracks: 6 (L/R + INPUT 1/2 + L/R ,backup)
USB
Mass Storage Class operation:	Class: USB 2.0 High ,Speed
Audio Interface operation: Multitrack mode:	Class: USB 2.0 High Speed Sampling frequency: 44.1/48kHz Bit rate: 16/24 bit Inputs / Outputs: 4 / ,2
Audio Interface operation: Stereo mode:	Class: USB 2.0 Full Speed Sampling frequency: 44.1/48kHz Bit rate: 16 bit Inputs / Outputs: 2 / ,2 USB bus powered operation possible (iPad operation supported in Stereo mode ,only)
Power Requirements
	AA size (LR6) battery x 2 AC adapter: AD-17 (DC5V/1A/USB-type) (optional) USB bus ,power

Attributter

Mer informasjon
SKU	H5
Vekt (kg)	0.050000
Enhet	Stk
EAN	4515260013241
Fabrikant	Zoom
Produktserie	Håndholdte opptakere
Farge	Svart
Tilkobling	XLR
